US LED Driver Filter Models: 8 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | PF | Efficiency | Certificate | Spec. | Sample Application |
| PIBU-K2 Series | 20-60 | 120-277 | 350-1500 | 30-42 | >0.9 | 86%-89% | UL FCC CUL | - | |
| PIBU020C0540VSRMK2 | 21.6 | 120-277 | 350-540 | 30-42 | >0.9 | 86% | UL FCC CUL | ||
| PIBU030C0800VSRMK2 | 30 | 120-277 | 420-800 | 30-42 | >0.9 | 87% | UL FCC CUL | ||
| PIBU040C1050VSRMK2 | 40 | 120-277 | 500-1050 | 30-42 | >0.9 | 88% | UL FCC CUL | ||
| PIBU050C1250VSRMK2 | 50 | 120-277 | 650-1250 | 30-42 | >0.9 | 89% | UL FCC CUL | ||
| PIBU060C1500VSRMK2 | 60 | 120-277 | 800-1500 | 30-42 | >0.9 | 89% | UL FCC CUL | ||
| PIBG-K2 Series | 20-60 | 120-347 | 350-1500 | 30-42 | ＞0.9 | 86%-89% | UL FCC CUL | - | |
| PIBG020C0540VSRMK2 | 21.6 | 120-347 | 350-540 | 30-42 | ＞0.9 | 86% | UL CCC CUL | ||
| PIBG030C0800VSRMK2 | 30 | 120-347 | 420-800 | 30-42 | ＞0.9 | 87% | UL FCC CUL | ||
| PIBG040C1050VSRMK2 | 40 | 120-347 | 500-1050 | 30-42 | ＞0.9 | 88% | UL FCC CUL | ||
| PIBG050C1250VSRMK2 | 50 | 120-347 | 650-1250 | 30-42 | ＞0.9 | 89% | UL FCC CUL | ||
| PIBG060C1500VSRMK2 | 60 | 120-347 | 800-1500 | 30-42 | ＞0.9 | 89% | UL FCC CUL | ||
| PIBU-J1 Series | 20-50 | 120-277 | 350-1250 | 30-42 | >0.9 | 86%-89% | UL FCC CUL | - | |
| PIBU020C0540VSRJ01 | 21.6 | 120-277 | 350-540 | 30-42 | ＞0.9 | 86% | UL FCC CUL | ||
| PIBU030C0800VSRJ01 | 30 | 120-277 | 420-800 | 30-42 | ＞0.9 | 87% | UL FCC CUL | ||
| PIBU040C1050VSRJ01 | 40 | 120-277 | 500-1050 | 30-42 | ＞0.9 | 88% | UL FCC CUL | ||
| PIBU050C1250VSRJ01 | 50 | 120-277 | 650-1250 | 30-42 | ＞0.9 | 89% | UL FCC CUL | ||
| PIBG-J1 Series | 20-50 | 120-347 | 350-1250 | 30-42 | >0.9 | 86%-89% | UL FCC CUL | - | |
| PIBG020C0540VSRJ01 | 21.6 | 120-347 | 350-540 | 30-42 | ＞0.9 | 86% | UL FCC CUL | ||
| PIBG030C0800VSRJ01 | 30 | 120-347 | 420-800 | 30-42 | ＞0.9 | 87% | UL FCC CUL | ||
| PIBG040C1050VSRJ01 | 40 | 120-347 | 500-1050 | 30-42 | ＞0.9 | 88% | UL FCC CUL | ||
| PIBG050C1250VSRJ01 | 50 | 120-347 | 650-1250 | 30-42 | ＞0.9 | 89% | UL FCC CUL | ||
| PGAM-M2 Series | 40-60 | 347-480 | 900-1400 | 30-42 | >0.9 | 84%-85% | UL | - | |
| PGAM040C0900VSLM2 | 40 | 347-480 | 900 | 30-42 | >0.9 | 84% | UL | ||
| PGAM040C0950VSLM2 | 40 | 347-480 | 950 | 30-42 | >0.9 | 84% | UL | ||
| PGAM040C1000VSLM2 | 40 | 347-480 | 1000 | 30-42 | >0.9 | 84% | UL | ||
| PGAM050C1050VSLM2 | 50 | 347-480 | 1050 | 30-42 | >0.9 | 84% | UL | ||
| PGAM050C1100VSLM2 | 50 | 347-480 | 1100 | 30-42 | >0.9 | 84% | UL | ||
| PGAM050C1150VSLM2 | 50 | 347-480 | 1150 | 30-42 | >0.9 | 84% | UL | ||
| PGAM050C1200VSLM2 | 50 | 347-480 | 1200 | 30-42 | >0.9 | 84% | UL | ||
| PGAM060C1250VSLM2 | 60 | 347-480 | 1250 | 30-42 | >0.9 | 85% | UL | ||
| PGAM060C1300VSLM2 | 60 | 347-480 | 1300 | 30-42 | >0.9 | 85% | UL | ||
| PGAM060C1350VSLM2 | 60 | 347-480 | 1350 | 30-42 | >0.9 | 85% | UL | ||
| PGAM060C1400VSLM2 | 60 | 347-480 | 1400 | 30-42 | >0.9 | 85% | UL | ||
| PGAM-M2-AUX Series | 40-60 | 347-480 | 900-1400 | 30-42 | >0.9 | 83%-84% | UL | - | |
| PGAM040C0900VSLM2-AUX | 40 | 347-480 | 900 | 30-42 | >0.9 | 83% | UL | ||
| PGAM040C0950VSLM2-AUX | 40 | 347-480 | 950 | 30-42 | >0.9 | 83% | UL | ||
| PGAM040C1000VSLM2-AUX | 40 | 347-480 | 1000 | 30-42 | >0.9 | 83% | UL | ||
| PGAM050C1050VSLM2-AUX | 50 | 347-480 | 1050 | 30-42 | >0.9 | 83% | UL | ||
| PGAM050C1100VSLM2-AUX | 50 | 347-480 | 1100 | 30-42 | >0.9 | 83% | UL | ||
| PGAM050C1150VSLM2-AUX | 50 | 347-480 | 1150 | 30-42 | >0.9 | 83% | UL | ||
| PGAM050C1200VSLM2-AUX | 50 | 347-480 | 1200 | 30-42 | >0.9 | 83% | UL | ||
| PGAM060C1250VSLM2-AUX | 60 | 347-480 | 1250 | 30-42 | >0.9 | 84% | UL | ||
| PGAM060C1300VSLM2-AUX | 60 | 347-480 | 1300 | 30-42 | >0.9 | 84% | UL | ||
| PGAM060C1350VSLM2-AUX | 60 | 347-480 | 1350 | 30-42 | >0.9 | 84% | UL | ||
| PGAM060C1400VSLM2-AUX | 60 | 347-480 | 1400 | 30-42 | >0.9 | 84% | UL | ||
| PGAM-M3 Series | 80-100 | 347-480 | 1500-2400 | 30-42 | >0.9 | 87% | UL | - | |
| PGAM080C1500VSLM3 | 80 | 347-480 | 1500 | 30-42 | >0.9 | 87% | UL | ||
| PGAM080C1600VSLM3 | 80 | 347-480 | 1600 | 30-42 | >0.9 | 87% | UL | ||
| PGAM080C1700VSLM3 | 80 | 347-480 | 1700 | 30-42 | >0.9 | 87% | UL | ||
| PGAM080C1800VSLM3 | 80 | 347-480 | 1800 | 30-42 | >0.9 | 87% | UL | ||
| PGAM080C1900VSLM3 | 80 | 347-480 | 1900 | 30-42 | >0.9 | 87% | UL | ||
| PGAM100C2000VSLM3 | 100 | 347-480 | 2000 | 30-42 | >0.9 | 87% | UL | ||
| PGAM100C2100VSLM3 | 100 | 347-480 | 2100 | 30-42 | >0.9 | 87% | UL | ||
| PGAM100C2200VSLM3 | 100 | 347-480 | 2200 | 30-42 | >0.9 | 87% | UL | ||
| PGAM100C2300VSLM3 | 100 | 347-480 | 2300 | 30-42 | >0.9 | 87% | UL | ||
| PGAM100C2350VSLM3 | 100 | 347-480 | 2350 | 30-40 | >0.9 | 87% | UL | ||
| PGAM100C2400VSLM3 | 100 | 347-480 | 2400 | 30-40 | >0.9 | 87% | UL | ||
| PGAM-M3-AUX Series | 80-100 | 347-480 | 1500-2400 | 30-42 | >0.9 | 86% | UL | - | |
| PGAM080C1500VSLM3-AUX | 80 | 347-480 | 1500 | 30-42 | >0.9 | 86% | UL | ||
| PGAM080C1600VSLM3-AUX | 80 | 347-480 | 1600 | 30-42 | >0.9 | 86% | UL | ||
| PGAM080C1700VSLM3-AUX | 80 | 347-480 | 1700 | 30-42 | >0.9 | 86% | UL | ||
| PGAM080C1800VSLM3-AUX | 80 | 347-480 | 1800 | 30-42 | >0.9 | 86% | UL | ||
| PGAM080C1900VSLM3-AUX | 80 | 347-480 | 1900 | 30-42 | >0.9 | 86% | UL | ||
| PGAM100C2000VSLM3-AUX | 100 | 347-480 | 2000 | 30-42 | >0.9 | 86% | UL | ||
| PGAM100C2100VSLM3-AUX | 100 | 347-480 | 2100 | 30-42 | >0.9 | 86% | UL | ||
| PGAM100C2200VSLM3-AUX | 100 | 347-480 | 2200 | 30-42 | >0.9 | 86% | UL | ||
| PGAM100C2300VSLM3-AUX | 100 | 347-480 | 2300 | 30-42 | >0.9 | 86% | UL | ||
| PGAM100C2400VSLM3-AUX | 100 | 347-480 | 2400 | 30-40 | >0.9 | 86% | UL |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
