PYG Filter Models: 8 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | PF | Efficiency | Certificate | Spec. | Sample Application |
| PYG40W Series | 40 | 36-72 | 800-1100 | 27-72 | >0.9 | 83%-84% | UL CCC CE | - | |
| PYG40W-54-C1110-RP-P-W | 40 | 36-54 | 1100 | 27-54 | >0.9 | 83% | UL CCC CE | ||
| PYG40W-54-C1110-RP-P | 40 | 36-54 | 1100 | 27-54 | >0.9 | 83% | UL CCC CE | ||
| PYG40W-72-C0800-RP-P-W | 40 | 50-72 | 800 | 36-72 | >0.9 | 84% | UL CCC CE | ||
| PYG40W-72-C0800-RP-P | 40 | 50-72 | 800 | 36-72 | >0.9 | 84% | UL CCC CE | ||
| PYG60W Series | 60 | 36-86 | 350-1670 | 27-86 | >0.9 | 84.5% | UL CCC CE | - | |
| PYG60W-54-C1670-RP-P-W | 60 | 36-54 | 350-1670 | 27-54 | >0.9 | 84.5% | UL CCC CE | ||
| PYG60W-86-C1100-RP-P-w | 60 | 54-86 | 350-1100 | 43-86 | >0.9 | 84.5% | UL CCC CE | ||
| PYG60W-54-C1670-RP-P | 60 | 36-54 | 350-1670 | 27-54 | >0.9 | 84.5% | UL CCC CE | ||
| PYG60W-86-C1100-RP-P | 60 | 54-86 | 350-1100 | 43-86 | >0.9 | 84.5% | UL CCC CE | ||
| PYG75W Series | 75 | 100-277 | 156-3125 | 24-107 | >0.9 | 88%-93% | UL CCC CE | - | |
| PYG75W-56-C2100-RP-P-W | 75 | 100-277 | 350-2100 | 28-56 | >0.9 | 89%-92% | UL CCC CE | ||
| PYG75W-107-C1050-RP-P-W | 75 | 100-277 | 350-1050 | 53-107 | >0.9 | 90%-93% | UL CCC CE | ||
| PYG75W-24-P-W | 75 | 100-277 | 312-3125 | 24 | >0.9 | 88%-90% | UL CCC CE | ||
| PYG75W-48-P-W | 75 | 100-277 | 156-1560 | 48 | >0.9 | 90%-93% | UL CCC CE | ||
| PYG150W Series | 150 | 100-277 | 350-4200 | 28-214 | >0.9 | 88%-91% | UL CCC CE | - | |
| PYG150W-56-C4200-RP-P-W | 150 | 100-277 | 700-4200 | 28-56 | >0.9 | 88%-91% | UL CCC CE | ||
| PYG150W-107-C2100-RP-P-W | 150 | 100-277 | 500-2100 | 53-107 | >0.9 | 89%-91% | UL CCC CE | ||
| PYG150W-214-C1000-RP-P-W | 150 | 100-277 | 350-1000 | 107-214 | >0.9 | 89%-91% | UL CCC CE | ||
| PYG100W Series | 100 | 100-277 | 300-4000 | 24-192 | >0.9 | 88%-93% | UL CCC CE | - | |
| PYG100W-56-C2670-RP-P-W | 100 | 100-277 | 350-2670 | 28-56 | >0.9 | 89%-92% | UL CCC CE | ||
| PYG100W-107-C1400-RP-P-W | 100 | 100-277 | 350-1400 | 53-107 | >0.9 | 89%-92% | UL CCC CE | ||
| PYG100W-192-C0690-RP-P-W | 100 | 100-277 | 300-690 | 96-192 | >0.9 | 89%-93% | UL | ||
| PYG100W-24-P-W | 100 | 100-277 | 4000 | 24 | >0.9 | 88%-92% | UL | ||
| PYG100W-48-P-W | 100 | 100-277 | 2000 | 48 | >0.9 | 89%-93% | UL | ||
| PYG200W Series | 200 | 100-277 | 350-5600 | 28-286 | >0.9 | 90%-94% | UL CCC CE | - | |
| PYG200W-56-C5600-RP-P-W | 200 | 100-277 | 700-5600 | 28-56 | >0.9 | 90%-93% | UL CCC CE | ||
| PYG200W-150-C2100-RP-P-W | 200 | 100-277 | 500-2100 | 75-150 | >0.9 | 92%-94% | UL CCC CE | ||
| PYG200W-286-C1100-RP-P-W | 200 | 100-277 | 350-1100 | 143-286 | >0.9 | 92%-94% | UL CCC CE | ||
| PYG240W Series | 240 | 100-277 | 350-6700 | 28-342 | >0.9 | 88%-92% | UL CCC CE | - | |
| PYG240W-56-C6700-RP-P-W | 240 | 100-277 | 700-6700 | 28-56 | >0.9 | 88%-92% | UL CCC CE | ||
| PYG240W-180-C2100-RP-P-W | 240 | 100-277 | 500-2100 | 90-180 | >0.9 | 88%-92% | UL CCC CE | ||
| PYG240W-342-C1100-RP-P-W | 240 | 100-277 | 350-1100 | 171-342 | >0.9 | 88%-92% | UL CCC CE | ||
| PYG320W Series | 320 | 100-277 | 350-7600 | 30-457 | >0.9 | 91%-95% | UL CCC CE | - | |
| PYG320W-60-C7600-RP-P-W | 320 | 100-277 | 1500-7600 | 30-60 | >0.9 | 91%-94% | UL CCC CE | ||
| PYG320W-240-C2100-RP-P-W | 320 | 100-277 | 500-2100 | 120-240 | >0.9 | 92%-95% | UL CCC CE | ||
| PYG320W-457-C1100-RP-P-W | 320 | 100-277 | 350-1100 | 229-457 | >0.9 | 92%-95% | UL CCC CE |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
