EU LED Driver_FUANTRONICS-PAIRUI

EU LED Driver

PSPL Series

PPL-D Series (17-25W Built-in)

PPL-D Series (17-25W External)

PPL-D Series (36-44W Built-in)

PPL-IP40 Series

PXV-30W Series

PXV-60W Series

PXV-120W Series

PXV-180W Series

Click to expand the criteria search box

EU LED Driver Filter Models: 5 in total, please see the table below.

Series

Rated power（W）

Input voltage（V）

Output current（mA）

Output voltage（V）

Efficiency

Certificate

Spec.

Sample Application

PSPL Series	14-40	220-240	350-1050	24-120	89%	CCC CB CE	-
PSPL-40-C0350-IP-15	14	220-240	350	24-42	89%	CCC CB CE
PSPL-40-C0350-IP-25	14	220-240	350	24-42	89%	CCC CB CE
PSPL-40-C0400-IP-15	16.8	220-240	400	24-42	89%	CCC CB CE
PSPL-40-C0400-IP-25	16.8	220-240	400	24-42	89%	CCC CB CE
PSPL-40-C0450-IP-15	18.9	220-240	450	24-42	89%	CCC CB CE
PSPL-40-C0450-IP-25	18.9	220-240	450	24-42	89%	CCC CB CE
PSPL-40-C0500-IP-15	21	220-240	500	24-42	89%	CCC CB CE
PSPL-40-C0500-IP-25	21	220-240	500	24-42	89%	CCC CB CE
PSPL-40-C0550-IP-15	23.1	220-240	550	24-42	89%	CCC CB CE
PSPL-40-C0550-IP-25	23.1	220-240	550	24-42	89%	CCC CB CE
PSPL-40-C0600-IP-15	25.2	220-240	600	24-42	89%	CCC CB CE
PSPL-40-C0600-IP-25	25.2	220-240	600	24-42	89%	CCC CB CE
PSPL-40-C0650-IP-15	27.3	220-240	650	24-42	89%	CCC CB CE
PSPL-40-C0650-IP-25	27.3	220-240	650	24-42	89%	CCC CB CE
PSPL-40-C0700-IP-15	29.4	220-240	700	24-42	89%	CCC CB CE
PSPL-40-C0700-IP-25	29.4	220-240	700	24-42	89%	CCC CB CE
PSPL-40-C0750-IP-15	31.5	220-240	750	24-42	89%	CCC CB CE
PSPL-40-C0750-IP-25	31.5	220-240	750	24-42	89%	CCC CB CE
PSPL-40-C0800-IP-15	33.6	220-240	800	24-42	89%	CCC CB CE
PSPL-40-C0800-IP-25	33.6	220-240	800	24-42	89%	CCC CB CE
PSPL-40-C0850-IP-15	35.7	220-240	850	24-42	89%	CCC CB CE
PSPL-40-C0850-IP-25	35.7	220-240	850	24-42	89%	CCC CB CE
PSPL-40-C0900-IP-15	37.8	220-240	900	24-42	89%	CCC CB CE
PSPL-40-C0900-IP-25	37.8	220-240	900	24-42	89%	CCC CB CE
PSPL-40-C0950-IP-15	39.9	220-240	950	24-42	89%	CCC CB CE
PSPL-40-C0950-IP-25	39.9	220-240	950	24-42	89%	CCC CB CE
PSPL-40-C1000-IP-15	40	220-240	1000	24-40	89%	CCC CB CE
PSPL-40-C1000-IP-25	40	220-240	1000	24-40	89%	CCC CB CE
PSPL-40-C1050-IP-15	39.9	220-240	1050	24-38	89%	CCC CB CE
PSPL-40-C1050-IP-25	39.9	220-240	1050	24-38	89%	CCC CB CE
PSPL-120-C0350-IP-15	40	220-240	350	72-120	89%	CCC CB CE
PSPL-120-C0350-IP-25	40	220-240	350	72-120	89%	CCC CB CE
PSPL-55-C0350-IP-15	19.25	220-240	350	33-55	89%	CCC CB CE
PSPL-55-C0350-IP-25	19.25	220-240	350	33-55	89%	CCC CB CE
PPL-D Series	17-44	220-240	250-1050	9-42	85%-91%	CB CE	-
PPL17W-42-C0400-D-A External	17	220-240	250-400	9-42	85.5%	CB CE
PPL17W-42-C0400-D-A Built-in	17	220-240	250-400	9-42	85.5%	CB CE
PPL17W-42-C0400-D-B External	17	220-240	250-400	9-42	85.5%	CB CE
PPL17W-42-C0400-D-B Built-in	17	220-240	250-400	9-42	85.5%	CB CE
PPL25W-42-C0600-D-A External	25	220-240	450-600	9-42	88%	CB CE
PPL25W-42-C0600-D-A Built-in	25	220-240	450-600	9-42	88%	CB CE
PPL25W-42-C0600-D-B External	25	220-240	450-600	9-42	88%	CB CE
PPL25W-42-C0600-D-B Built-in	25	220-240	450-600	9-42	88%	CB CE
PPL36W-42-C0850-D-A Built-in	36	220-240	600-850	9-42	90.5%	CB CE
PPL36W-42-C0850-D-B Built-in	36	220-240	600-850	9-42	90.5%	CB CE
PPL44W-42-C1050-D-A Built-in	44	220-240	900-1050	9-42	91%	CB CE
PPL44W-42-C1050-D-B Built-in	44	220-240	900-1050	9-42	91%	CB CE
PPL-IP40 Series	26-40	220-240	300-1000	24-95	86%-90%	CCC CB CE	-
PPL-40-C0650-IP	26	220-240	650	24-40	87%	CCC CB CE
PPL-40-C0700-IP	28	220-240	700	24-40	87%	CCC CB CE
PPL-40-C0750-IP	30	220-240	750	24-40	88%	CCC CB CE
PPL-40-C0800-IP	32	220-240	800	24-40	88%	CCC CB CE
PPL-40-C0850-IP	34	220-240	850	24-40	89%	CCC CB CE
PPL-40-C0900-IP	36	220-240	900	24-40	89%	CCC CB CE
PPL-40-C0950-IP	38	220-240	950	24-40	90%	CCC CB CE
PPL-40-C1000-IP	40	220-240	1000	24-40	90%	CCC CB CE
PPL-42-C0650-IP	27	220-240	650	24-42	86%	CCC CB CE
PPL-42-C0700-IP	29	220-240	700	24-42	86%	CCC CB CE
PPL-42-C0750-IP	32	220-240	750	24-42	88%	CCC CB CE
PPL-42-C0800-IP	34	220-240	800	24-42	88%	CCC CB CE
PPL-42-C0850-IP	36	220-240	850	24-42	89%	CCC CB CE
PPL-42-C0900-IP	38	220-240	900	24-42	89%	CCC CB CE
PPL-42-C0950-IP	40	220-240	950	24-42	90%	CCC CB CE
PPL-55-C0500-IP	28	220-240	500	33-55	86%	CCC CB CE
PPL-55-C0550-IP	30	220-240	550	33-55	87%	CCC CB CE
PPL-55-C0600-IP	33	220-240	600	33-55	87.5%	CCC CB CE
PPL-55-C0650-IP	36	220-240	650	33-55	88%	CCC CB CE
PPL-55-C0700-IP	39	220-240	700	33-55	89.5%	CCC CB CE
PPL-55-C0750-IP	40	220-240	730	33-55	89.5%	CCC CB CE
PPL-76-C0350-IP	27	220-240	350	46-76	86%	CCC CB CE
PPL-76-C0400-IP	30	220-240	400	46-76	87%	CCC CB CE
PPL-76-C0450-IP	34	220-240	450	46-76	87%	CCC CB CE
PPL-76-C0500-IP	38	220-240	500	46-76	87%	CCC CB CE
PPL-95-C0300-IP	29	220-240	300	57-95	86%	CCC CB CE
PPL-95-C0350-IP	33	220-240	350	57-95	87%	CCC CE
PPL-95-C0400-IP	38	220-240	400	57-95	87%	CCC CB CE
PXD Series	19-75	220-240	250-1400	27-54	84%-89%	CCC CB CE	-
PXD19W-54-C0350-F	18.9	220-240	250-350	27-54	84%	CCC CB CE
PXD38W-54-C0700-F	37.8	220-240	400-700	27-54	87%	CCC CB CE
PXD57W-54-C1050-F	56.7	220-240	700-1050	27-54	88%	CCC CB CE
PXD75W-54-C1400-F	75.6	220-240	1100-1400	27-54	89%	CCC CB CE
PXF Series	20-75	220-240	200-550	27-216	87%-94%	CCC CB CE	-
PXF20W-67-C0350	20	220-240	200-350	27-67	87%	CCC CB CE
PXF20W-67-C0350-K	20	220-240	200-350	27-67	87%	CCC CB CE
PXF40W-133-C0350-K	40	220-240	200-350	50-133	90%	CCC CB CE
