PPL-D

PPL-D Series(17-25W Built-in)
PPL-D Series(17-25W External)
PPL-D Series(36-44W)
Click to expand the criteria search box

  • Product number

    • {/php}

  • Rated power（W）

  • Input voltage（V）

  • Output current（mA）

  • Output voltage（V）

PPL-D Filter Models: 6 in total, please see the table below.

Series Rated power（W） Input voltage（V） Output current（mA） Output voltage（V） PF Efficiency Certificate Spec. Sample Application
PPL-D Series(17W Built-in)
11-17 220-240 250-400 9-42 0.9 83%-85.5% CCC CB CE
-
PPL17W-42-C0400-D-A
17 220-240 400 9-42 0.9 85.5% CCC CB CE
PPL17W-42-C0400-D-B
17 220-240 400 9-42 0.9 85.5% CCC CB CE
PPL17W-42-C0400-A
17 220-240 400 9-42 0.9 85.5% CCC CB CE
PPL17W-42-C0400-B
17 220-240 400 9-42 0.9 85.5% CCC CB CE
PPL15W-42-C0350-A
15 220-240 350 9-42 0.9 84.8% CCC CB CE
PPL15W-42-C0350-B
15 220-240 350 9-42 0.9 84.8% CCC CB CE
PPL13W-42-C0300-A
13 220-240 300 9-42 0.9 84% CCC CB CE
PPL13W-42-C0300-B
13 220-240 300 9-42 0.9 84% CCC CB CE
PPL11W-42-C0250-A
11 220-240 250 9-42 0.9 83% CCC CB CE
PPL11W-42-C0250-B
11 220-240 250 9-42 0.9 83% CCC CB CE
PPL-D Series(25W Built-in)
19-25 220-240 450-600 9-42 0.9 87%-88% CCC CB CE
-
PPL25W-42-C0600-D-A
25 220-240 600 9-42 0.9 88% CCC CB CE
PPL25W-42-C0600-D-B
25 220-240 600 9-42 0.9 88% CCC CB CE
PPL23W-42-C0550-A
23 220-240 550 9-42 0.9 87.8% CCC CB CE
PPL23W-42-C0550-B
23 220-240 550 9-42 0.9 87.8% CCC CB CE
PPL-D Series(17W External)
11-17 220-240 250-400 9-42 0.9 83%-85.5% CCC CB CE
-
PPL-D Series(25W External)
19-25 220-240 450-600 9-42 0.9 87%-88% CCC CB CE
-
PPL-D Series(36W)
25-36 220-240 600-850 9-42 0.9 86%-90.5% CCC CB CE
-
PPL-D Series(44W)
38-44 220-240 900-1050 9-42 0.9 90.5%-91% CCC CB CE
-

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters

Series
PPL-D Series(17W Built-in)
PPL17W-42-C0400-D-A
PPL17W-42-C0400-D-B
PPL17W-42-C0400-A
PPL17W-42-C0400-B
PPL15W-42-C0350-A
PPL15W-42-C0350-B
PPL13W-42-C0300-A
PPL13W-42-C0300-B
PPL11W-42-C0250-A
PPL11W-42-C0250-B
PPL-D Series(25W Built-in)
PPL25W-42-C0600-D-A
PPL25W-42-C0600-D-B
PPL23W-42-C0550-A
PPL23W-42-C0550-B
PPL-D Series(17W External)
PPL-D Series(25W External)
PPL-D Series(36W)
PPL-D Series(44W)
