PYG Series
Click to expand the criteria search box
PYG Series Filter Models: 8 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | Efficiency | Certificate | Spec. | PF | Sample Application |
| PYG 40W Series | 40W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PYG40W-54-C1110-RP-P-W | 40W | 100-277Vac | 100mA-1110mA | 27-54Vdc | 86.0% | UL CCC CE | ＞0.9 | ||
| PYG40W-54-C1110-RP-P | 40W | 100-277Vac | 100mA-1110mA | 27-54Vdc | 86.0% | UL CCC FCC | ＞0.9 | ||
| PYG40W-72-C0800-RP-P-W | 40W | 100-277Vac | 100-800mA | 50-72Vdc | 86.5% | CCC CB CE | ＞0.9 | ||
| PYG40W-72-C0800-RP-P | 40W | 100-277Vac | 100-800mA | 50-72Vdc | 86.5% | UL CCC CE | ＞0.9 | ||
| PYG 60W Series | 60W | 100-277Vac | - | - | - | UL CB CE | ＞0.9 | - | |
| PYG60W-54-C1670-RP-P-W | 60W | 100-277Vac | 350-1670mA | 36-54Vdc | 87.0% | UL CCC CE | ＞0.9 | ||
| PYG60W-86-C1100-RP-P-W | 60W | 100-277Vac | 350-1100mA | 54-86Vdc | 87.0% | UL CCC CE | ＞0.9 | ||
| PYG60W-54-C1670-RP-P | 60W | 100-277Vac | 350-1670mA | 36-54Vdc | 87.0% | UL CCC CE | ＞0.9 | ||
| PYG60W-86-C1100-RP-P | 60W | 100-277Vac | 350-1100mA | 54-86Vdc | 87.5% | UL CCC CB | ＞0.9 | ||
| PYG75W Series | 75W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PYG75W-56-C2100-RP-P-W | 75W | 100-277Vac | 350-2100mA | 28-56Vdc | 88% | UL CCC CE | ＞0.9 | ||
| PYG75W-107-C1050-RP-P-W | 75W | 100-277Vac | 350-1050mA | 53-107Vdc | 88% | UL CCC CE | ＞0.9 | ||
| PYG75W-24-P-W | 75W | 100-277Vac | 3100mA | 24Vdc | 88% | UL CCC CE | ＞0.9 | ||
| PYG75W-48-P-W | 75W | 100-277Vac | 1560mA | 48Vdc | 90% | UL CCC CE | ＞0.9 | ||
| PYG100W Series | 100W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PVG100W-56-C2670-RP-P-W | 100W | 100-277Vac | 350-2670mA | 28-56Vdc | 92% | UL CCC CE | ＞0.9 | ||
| PYG100W-107-C1400-RP-P-W | 100W | 100-277Vac | 350-1400mA | 53-107Vdc | 92% | UL CCC CE | ＞0.9 | ||
| PYG100W-192-C0800-RP-P-W | 100W | 100-277Vac | 300-800mA | 96-192Vdc | 92% | UL CCC CE | ＞0.9 | ||
| PYG100W-24-P-W | 100W | 100-277Vac | 4200mA | 24Vdc | 92% | UL CCC CE | ＞0.9 | ||
| PYG100W-48-P-W | 100W | 100-277Vac | 2080mA | 48Vdc | 92% | UL CCC CE | ＞0.9 | ||
| PYG150W Series | 150W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PYG150W-56-C4200-RP-P-W | 150W | 100-277Vac | 700-4200mA | 28-56Vdc | 93% | UL CCC CE | ＞0.9 | ||
| PYG150W-107-C2080-RP-P-W | 150W | 100-277Vac | 500-2100mA | 56-107Vdc | 93% | UL CCC CE | ＞0.9 | ||
| PYG150W-214-C1100-RP-P-W | 150W | 100-277Vac | 350-1000mA | 107-214Vdc | 93% | UL CCC CE | ＞0.9 | ||
| PYG200W Series | 200W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PYG200W-56-C5600-RP-P-W | 200W | 100-277Vac | 700-5600mA | 28-56Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PYG200W-150-C2100-RP-P-W | 200W | 100-277Vac | 500-2100mA | 75-150Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PYG200W-286-C1100-RP-P-W | 200W | 100-277Vac | 350-1100mA | 143-286Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PYG240W Series | 240W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PYG240W-56-C6700-RP-P-W | 240W | 100-277Vac | 700-6700mA | 28-56Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PYG240W-180-C2100-RP-P-W | 240W | 100-277Vac | 500-2100mA | 90-180Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PVG240W-342-C1100-RP-P-W | 240W | 100-277Vac | 350-1100mA | 171-342Vdc | 94% | UL CCC CE | ＞0.9 | ||
| PYG320W Series | 320W | 100-277Vac | - | - | - | UL CCC CE | ＞0.9 | - | |
| PVG320W-60-C7600-RP-P-W | 320W | 100-277Vac | 1000-7600mA | 30-60Vdc | 95% | UL CCC CE | ＞0.9 | ||
| PYG320W-240-C2100-RP-P-W | 320W | 100-277Vac | 500-2100mA | 120-240Vdc | 95% | UL CCC CE | ＞0.9 | ||
| PYG320W-457-C1100-RP-P-W | 320W | 100-277Vac | 350-1100mA | 229-457Vdc | 95% | UL CCC CE | ＞0.9 |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
