DAE2-1224F
*The picture is for reference only, please refer to the actual product/technical specification for specific parameters
DC-DC-DC-DC Module SIP
- 型号：DAE2-1224F
- Rated power（W）: 2.00
- Input voltage（V）: 12(10.8~13.2)
- Output current（mA）: 68
- Output voltage（V）: ±15
- Dimension (mm): 19.6x10.0x7.0
- Efficiency: 82.0%
- Isolation voltage（V）: 3000
- Winding No.: dual without isolation
- Package type: SIP
