DBR1-0525F
*The picture is for reference only, please refer to the actual product/technical specification for specific parameters
DC-DC-DC-DC Module SIP
- 型号：DBR1-0525F
- Rated power（W）: 1.00
- Input voltage（V）: 5(4.75~5.25)
- Output current（mA）: 21
- Output voltage（V）: ±24
- Dimension (mm): 27.5x12.0x9.5
- Efficiency: 62.0%
- Isolation voltage（V）: 3000
- Winding No.: dual without isolation
- Package type: SIP
