AAL
Click to expand the criteria search box
AAL Filter Models: 1 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | PF | Efficiency | Certificate | Spec. | Sample Application |
| AAL Series | 4-24 | 100-264 | 300-350 | 3-54 | 0.9 | 66%-85% | CE | - | |
| AAL4-C300 | 4 | 100-264 | 300 | 3-14 | 0.9 | 66% | CE | ||
| AAL7-C300 | 7 | 100-264 | 300 | 9-20 | 0.9 | 70% | CE | ||
| AAL12-C350 | 12 | 100-264 | 350 | 15-33 | 0.9 | 82% | CE | ||
| AAL18-C350 | 18 | 100-264 | 350 | 30-50 | 0.9 | 82% | CE | ||
| AAL24-C350 | 24 | 100-264 | 350 | 36-54 | 0.9 | 85% | CE |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
