Common Mode & Differential Mode Inductor Filter Models: 8 in total, please see the table below.

Series Inductance Leakage inductance DCR Load current Spec. Sample Application
FAPK17-1
3.3-100mH 96-3000uH 0.078-3Ω 0.3-2A
-
FAPK17-332001
3.3mH 96uH 0.078Ω 2A
FAPK17-472001
4.7mH 135uH 0.115Ω 1.6A
FAPK17-682001
6.8mH 195uH 0.155Ω 1.3A
FAPK17-103001
10mH 295uH 0.235Ω 1A
FAPK17-153001
15mH 455uH 0.35Ω 0.85A
FAPK17-203001
20mH 585uH 0.44Ω 0.75A
FAPK17-253001
25mH 750uH 0.67Ω 0.65A
FAPK17-333001
33mH 985uH 0.8Ω 0.6A
FAPK17-393001
39mH 1200uH 0.5A
FAPK17-473001
47mH 1400uH 1.28Ω 0.45A
FAPK17-823001
82mH 2400uH 2.2Ω 0.35A
FAPK17-104001
100mH 3000uH 0.3A
FAPK17-2
3.3-100mH 87-2800uH 0.078-3Ω 0.3-2A
-
FAPK17-332002
3.3mH 87uH 0.078Ω 2A
FAPK17-472002
4.7mH 125uH 0.115Ω 1.6A
FAPK17-682002
6.8mH 180uH 0.155Ω 1.3A
FAPK17-103002
10mH 270uH 0.235Ω 1A
FAPK17-153002
15mH 410uH 0.35Ω 0.85A
FAPK17-203002
20mH 540uH 0.44Ω 0.75A
FAPK17-253002
25mH 700uH 0.67Ω 0.65A
FAPK17-333002
33mH 900uH 0.8Ω 0.6A
FAPK17-393002
39mH 1100uH 0.5A
FAPK17-473002
47mH 1300uH 1.28Ω 0.45A
FAPK17-823002
82mH 2200uH 2.2Ω 0.35A
FAPK17-104002
100mH 2800uH 0.3A
FAPK17-3
3.3-100mH 78-2500uH 0.078-3Ω 0.3-2A
-
FAPK17-332003
3.3mH 78uH 0.078Ω 2A
FAPK17-472003
4.7mH 108uH 0.115Ω 1.6A
FAPK17-682003
6.8mH 155uH 0.155Ω 1.3A
FAPK17-103003
10mH 235uH 0.235Ω 1A
FAPK17-153003
15mH 365uH 0.35Ω 0.85A
FAPK17-203003
20mH 470uH 0.44Ω 0.75A
FAPK17-253003
25mH 600uH 0.67Ω 0.65A
FAPK17-333003
33mH 800uH 0.8Ω 0.6A
FAPK17-393003
39mH 950uH 0.5A
FAPK17-473003
47mH 1100uH 1.28Ω 0.45A
FAPK17-823003
82mH 2000uH 2.2Ω 0.35A
FAPK17-104003
100mH 2500uH 0.3A
FACCF16H
10-100mH 200-1930uH 0.29-2.93Ω 0.45-1.6A
-
FACCF16H-103Y1R6
10mH 200uH 0.29Ω 1.6A
FACCF16H-153Y1R3
15mH 290uH 0.43Ω 1.3A
FACCF16H-273Y0R9
27mH 520uH 0.77Ω 0.9A
FACCF16H-393Y0R8
39mH 760uH 1.1Ω 0.8A
FACCF16H-473Y0R7
47mH 920uH 1.26Ω 0.7A
FACCF16H-683Y0R6
68mH 1340uH 1.97Ω 0.6A
FACCF16H-104Y0R45
100mH 1930uH 2.93Ω 0.45A
FACCF23H
10-100mH 200-2100uH 0.188-1.81Ω 0.7-2.3A
-
FACCF23H-103Y2R3
10mH 200uH 0.188Ω 2.3A
FACCF23H-153Y1R9
15mH 310uH 0.279Ω 1.9A
FACCF23H-273Y1R4
27mH 530uH 0.44Ω 1.4A
FACCF23H-393Y1R2
39mH 800uH 0.696Ω 1.2A
FACCF23H-473Y1R1
47mH 970uH 0.804Ω 1.1A
FACCF23H-683Y0R9
68mH 1440uH 1.1Ω 0.9A
FACCF23H-104Y0R7
100mH 2100uH 1.81Ω 0.7A
FACCF23V
10-100mH 200-2100uH 0.188-1.81Ω 0.7-2.3A
-
FACCF23V-103Y2R3
10mH 200uH 0.188Ω 2.3A
FACCF23V-153Y1R9
15mH 310uH 0.279Ω 1.9A
FACCF23V-273Y1R4
27mH 530uH 0.44Ω 1.4A
FACCF23V-393Y1R2
39mH 800uH 0.696Ω 1.2A
FACCF23V-473Y1R1
47mH 970uH 0.804Ω 1.1A
FACCF23V-683Y0R9
68mH 1440uH 1.1Ω 0.9A
FACCF23V-104Y0R7
100mH 2100uH 1.81Ω 0.7A
FACCF23BH
10-100mH 375-3600uH 0.188-1.81Ω 0.7-2.3A
-
FACCF23BH-103Y2R3
10mH 375uH 0.188Ω 2.3A
FACCF23BH-153Y1R9
15mH 530uH 0.279Ω 1.9A
FACCF23BH-273Y1R4
27mH 1000uH 0.44Ω 1.4A
FACCF23BH-393Y1R2
39mH 1440uH 0.696Ω 1.2A
FACCF23BH-473Y1R1
47mH 1800uH 0.804Ω 1.1A
FACCF23BH-683Y0R9
68mH 2500uH 1.1Ω 0.9A
FACCF23BH-104Y0R7
100mH 3600uH 1.81Ω 0.7A
FACCF23BV
10-100mH 375-3600uH 0.188-1.81Ω 0.7-2.3A
-
FACCF23BV-103Y2R3
10mH 375uH 0.188Ω 2.3A
FACCF23BV-153Y1R9
15mH 530uH 0.279Ω 1.9A
FACCF23BV-273Y1R4
27mH 1000uH 0.44Ω 1.4A
FACCF23BV-393Y1R2
39mH 1440uH 0.696Ω 1.2A
FACCF23BV-473Y1R1
47mH 1800uH 0.804Ω 1.1A
FACCF23BV-683Y0R9
68mH 2500uH 1.1Ω 0.9A
FACCF23BV-104Y0R7
100mH 3600uH 1.81Ω 0.7A

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
