Mini Built-in Type

PIBH(High P)
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Output voltage(V)

  • Output current(mA)

  • Ripple

  • PF

  • Protection level

  • Series

Mini Built-in Type Filter Models: 4 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(mA) Output voltage(V) PF Efficiency Certificate Spec. Sample Application
PIBH003-P1
3 220-240 300,350 - 0.7 72% TUV CB CE
-
PIBH003C0300NSLPP1
3 220-240 300 5-13 0.7 72.0% TUV CB CE
PIBH003C0350NSLPP1
3 220-240 350 3-10 0.7 72.0% TUV CB CE
PIBH006-P1
6 220-240 300,350 - 0.7 75% TUV CB CE
-
PIBH006C0300NSLPP1
6 220-240 300 12-22 0.7 75.0% TUV CB CE
PIBH006C0350NSLPP1
6 220-240 350 9-18 0.7 75.0% TUV CB CE
PIBH009-P2
9 220-240 300,350 - 0.7 80% TUV CB CE
-
PIBH009C0300NSLPP2
9 220-240 300 20-32 0.7 80.0% TUV CB CE
PIBH009C0350NSLPP2
9 220-240 350 15-27 0.7 80.0% TUV CB CE
PIBH012-P2
12 220-240 300 - 0.7 82% TUV CB CE
-
PIBH012C0300NSLPP2
12 220-240 300 30-40 0.7 82.0% TUV CB CE

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
