PPL-D Series
Click to expand the criteria search box
PPL-D Series Filter Models: 1 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | Efficiency | Certificate | Spec. | PF | Sample Application |
| LPL-D-A&B | 17-42W | 220-240Vac | 250mA-1050mA | 9-42V | - | CB CE | - | ＞0.9 | - |
| LPL17W-42-C0400-D-A External | 17W | 220-240Vac | 250mA-400mA | 9-42V | 0.855 | CB CE | ＞0.9 | ||
| LPL17W-42-C0400-D-A Built-in | 17W | 220-240Vac | 250mA-400mA | 9-42V | 0.855 | CB CE | ＞0.9 | ||
| LPL17W-42-C0400-D-B External | 17W | 220-240Vac | 250mA-400mA | 9-42V | 0.855 | CB CE | ＞0.9 | ||
| LPL17W-42-C0400-D-B Built-in | 17W | 220-240Vac | 250mA-400mA | 9-42V | 0.855 | CB CE | ＞0.9 | ||
| LPL25W-42-C0600-D-A External | 25W | 220-240Vac | 450mA-600mA | 9-42V | 0.88 | CB CE | ＞0.9 | ||
| LPL25W-42-C0600-D-A Built-in | 25W | 220-240Vac | 450mA-600mA | 9-42V | 0.88 | CB CE | ＞0.9 | ||
| LPL25W-42-C0600-D-B External | 25W | 220-240Vac | 450mA-600mA | 9-42V | 0.88 | CB CE | ＞0.9 | ||
| LPL25W-42-C0600-D-B Built-in | 25W | 220-240Vac | 450mA-600mA | 9-42V | 0.88 | CB CE | ＞0.9 | ||
| PPL36W-42-C0850-D-A Built-in | 42W | 220-240Vac | 600mA-850mA | 9-42V | 0.905 | CB CE | ＞0.9 | ||
| PPL36W-42-C0850-D-B Built-in | 42W | 220-240Vac | 600mA-850mA | 9-42V | 0.905 | CB CE | ＞0.9 | ||
| PPL44W-42-C1050-D-A Built-in | 42W | 220-240Vac | 900mA-1050mA | 9-42V | 0.91 | CB CE | ＞0.9 | ||
| PPL44W-42-C1050-D-B Built-in | 42W | 220-240Vac | 900mA-1050mA | 9-42V | 0.91 | CB CE | ＞0.9 |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
